BLE
Blue PUCK DI
Bluetooth digital input sensor
The Blue PUCK DI with digital input is compatible with sensors providing a binary or on/off (discrete) output. It interfaces these sensors to the Bluetooth network and encodes their status in a Low Energy Bluetooth frame. This sensor can be used in many industrial applications such as tank level monitoring, shock detection, presence detection, or even pulse counting.
Benefits
Digital input
Autonomy
Waterproof
Rugged
- Technical Specifications
- Technical Documentation
- Accessories
- Customization
Technical Specifications
3 VDC – Internal lithium battery
Battery life : up to 20 yrs.
Battery life : up to 20 yrs.
2.4 GHz – Bluetooth Low Energy 4.0/4.2
Transmission power: up to +4 dBm (configurable)
Configurable by NFC
Over-the-air update (OTAP)
Transmission power: up to +4 dBm (configurable)
Configurable by NFC
Over-the-air update (OTAP)
Digital input sensor
High input: 2.1V to 3V
Low input: 0V to 0.7V
High input: 2.1V to 3V
Low input: 0V to 0.7V
Casing: Robust DELRIN (POM C) – Food quality
Ø 57mm base – H : 20mm
Weight: 41g
Operating temp:-20°C to +85°C
Protection class : IP65
Ø 57mm base – H : 20mm
Weight: 41g
Operating temp:-20°C to +85°C
Protection class : IP65
CE
UKCA
FCC
ISED
RoHs
UKCA
FCC
ISED
RoHs
Technical Documentation
Accessories
Customization
Customize your beacon and sensor firmware (BLE only).
Customize the label of your beacon and sensor park.
Create your own white marking label.
To receive our integrator rates,
our experts are here for you.
Use cases
Supervision and predictive maintenance
In Industry 4.0, supervision and predictive maintenance are major issues. In order to be able to anticipate, control and secure industrial equipment and buildings, ELA Innovation sensors allow to connect measuring instruments that were not previously connected: pressure, vibration, luminosity sensors... This wireless industrial solution allows to save money and minimize wiring costs. The little extra: A single industrial gateway is required to control several dozen actuators simultaneously.
Resources
SDK & code samples
Discover 1 software development kit (SDK) including microservices, APIs, sample code using these APIs and associated documentation. Also available are code examples compatible with different development environments.
Bluetooth Advanced Features
With the Bluetooth Advanced Features option, you can accelerate the deployment of your business solution and guarantee customer satisfaction. This service enables you to customize 100% of the frame of your ELA Innovation beacons & sensors. Configuration is carried out by our factory teams.
BLE Gateway & Web App
Discover our BLE Gateway Web App to configure your IoT network, scan and read your BLE devices in real time, view and download their data and send commands. This Gateway is ideal for testing ELA Innovation products.
