AOA

Blue LITE ID QUUPPA

Quuppa tracking tag
Smaller, stronger, smarter, the Blue Lite ID QUUPPA is the ideal tag for high-precision localization of people and small equipment by integrating easily with RTLS (Real Time Locating System) solutions. 100% autonomous, this tag based on the Angle of Arrival (AOA) technology can be used as a badge, but can also be attached to equipment thanks to its high-performance adhesive back.

Benefits

icon

High Accuracy

icon

LED

icon

Removable battery

icon

Real-time

icon

Compact

Schéma boitier LITE capteur ELA Innovation
For more details, please refer to the product data sheet
IDF28540-01A
3 VDC – Internal lithium battery
Battery life : up to 5 yrs.
Smart Battery Management
Replaceable battery: Yes
2.4 GHz – Bluetooth Low Energy 4.0/4.2
Transmission power: up to +4 dBm (configurable)
Transmission period from 0.1 to 10 sec.
Configurable by NFC
Over-the-air update (OTAP)
Compatibility: Quuppa
Tracking tag
Location accuracy: up to 10cm
LED: Yes
3 axis accelerometer
Casing: ABS+PC (UL94V0, medical grade)
45 x23.2×5.3 mm
Weight: 8g
Operating temp: -30°C to +70°C
CE
UKCA
FCC
ISED
RoHs
Quuppa Approved

Customize your beacon and sensor firmware (BLE only).

>> Find out more about Bluetooth Advanced Features

Customize the label of your beacon and sensor park.
Create your own white marking label.
